B-5
Rev 2.2, 10/31/94
STEP MRC Key MRC Displays Data to Set/Enter Comments
108 5E mfrID2
109 01 device type
110 00 unit/channel
111 1C edit buffer data set
112 page DEFINE SYSEX
BYTES 8-9
113 22 edit buffer 34
114 BYTE send slider setting
115 page LABEL FOR
slr1
116 D L Y 1 use sliders 1-4 to set label to "D L
Y 1"
Set slider 2 to control delay 2
117 page SOURCE DEST
OUT#
setup slider 2
118 SOURCE slr2 use button 1 to set source to slr2
119 DEST SYSEX use slider 2 to set DEST to SYSEX
120 OUT# 1 use slider 3 to set OUT# to 1
121 page DEFINE SYSEX
BYTES 2-3
122 F0 SYSEX
123 00 mfrID0
124 00 mfrID1
125 page DEFINE SYSEX
BYTES 4-7
126 5E mfrID2
127 01 device type
128 00 unit/channel
129 1C edit buffer data set
130 page DEFINE SYSEX
BYTES 8-9
131 23 edit buffer 35
132 BYTE send slider setting
133 page LABEL FOR
slr2
134 D L Y 2 use sliders 1-4 to set label to "D L
Y 2"
135 page SOURCE DEST
OUT#
Set slider 3 to control feedback (recirculation).
136 SOURCE slr3 use button 1 to set source to slr3
137 DEST SYSEX use slider 2 to set DEST to SYSEX
138 OUT# 1 use slider 3 to set OUT# to 1
139 page DEFINE SYSEX
BYTES 2-3
140 F0 SYSEX
141 00 mfrID0
142 00 mfrID1
143 page DEFINE SYSEX
BYTES 4-7
144 5E mfrID2
