WARNING/ALARM 30, Motor phase U missing
Motor phase U between the adjustable frequency drive
and the motor is missing.
Remove power from the adjustable frequency drive and
check motor phase U.
WARNING/ALARM 31, Motor phase V missing
Motor phase V between the adjustable frequency drive
and the motor is missing.
Remove power from the adjustable frequency drive and
check motor phase V.
WARNING/ALARM 30, Motor phase W missing
Motor phase W between the adjustable frequency drive
and the motor is missing.
Remove power from the adjustable frequency drive and
check motor phase W.
WARNING/ALARM 33, Inrush Fault
Too many power-ups have occurred within a short time
period. Let the unit cool to operating temperature.
WARNING/ALARM 34, Fieldbus Communication Fault
Communication between the serial communication bus
and the communication option card is not operating.
WARNING/ALARM 36, Mains Failure
This warning/alarm is only active if the supply voltage to
the adjustable frequency drive is lost and 14-10 Mains
Failure is NOT set to [0] No Function. Check the fuses to
the adjustable frequency drive and line power supply to
the unit.
WARNING/ALARM 36, Internal Fault
When an internal fault occurs, a code number defined in
the table below is displayed.
Troubleshooting
• Cycle power to the adjustable frequency drive.
• Check that the option is properly installed.
• Check for loose or missing wiring.
It may be necessary to contact your Danfoss supplier or
service department. Note the code number for further
troubleshooting directions.
WARNING/ALARM 39, Heatsink Sensor
No feedback from the heatsink temperature sensor.
The signal from the IGBT thermal sensor is not available
on the power card. The problem could be on the power
card, on the gate drive card, or the ribbon cable between
the power card and gate drive card.
WARNING/ALARM 40, Overload of digital output ter-
minal 27
Check the load connected to terminal 27 or remove
shortcircuit connection. Check 5-00 Digital I/O Mode and
5-01 Terminal 27 Mode.
WARNING/ALARM 40, Overload of digital output ter-
minal 29
Check the load connected to terminal 27 or remove
shortcircuit connection. Check 5-00 Digital I/O Mode and
5-01 Terminal 29 Mode.
WARNING/ALARM 40, Overload of digital output on
X30/6 or overload of digital ouput on x30/7
For X30/6, check the load connected to X30/6 or remove
short-circuit connection. Check 5-32 Term X30/6 Digi Out
(MCB 101).
No. Text
0 Serial port cannot be initialized. Contact your
Danfoss supplier or DanfossService Department.
256-258 Power EEPROM data is defect or too old.
512-519 Internal fault. Contact yourDanfoss supplier or
DanfossService Department.
783 Parameter value outside of min/max limits
1024-1284 Internal fault. Contact your Danfoss supplier or
the Danfoss Service Department.
1299 Option SW in slot A is too old.
1300 Option SW in slot B is too old.
1302 Option SW in slot C1 is too old.
1315 Option SW in slot A is not supported (not
allowed).
1316 Option SW in slot B is not supported (not
allowed).
1318 Option SW in slot C1 is not supported (not
allowed).
1379-2819 Internal fault. Contact yourDanfoss supplier or
DanfossService Department.
2820 LCP stack overflow.
2821 Serial port overflow.
2822 USB port overflow.
3072-5122 Parameter value is outside its limit.
5123 Option in slot A: Hardware incompatible with con-
trol board hardware.
5124 Option in slot B: Hardware incompatible with con-
trol board hardware.
5125 Option in slot C0: Hardware incompatible with
control board hardware.
5126 Option in slot C1: Hardware incompatible with
control board hardware.
5376-6231 Internal fault. Contact your Danfoss supplier or
DanfossService Department.
No. Text
