17 SPECIFICATIONS
17.1 Power-dependent Specifications
Table 10: Line Power Supply 200-240 V AC
Table 11: Line Power Supply 3 x 200-240 V AC
Table 12: Line Power Supply 3 x 200-240 V AC
Table 13: Line Power Supply 3 x 380-480 V AC
Line Power Supply 200-240 V AC - Normal overload 110% for 1 minute
Adjustable frequency drive
Typical Shaft Output [kW]
P1K1
1.1
P1K5
1.5
P2K2
2.2
P3K0
3
P3K7
3.7
IP20, IP21 max. cable cross-section (line power, motor,
brake and load sharing) [mm
2
(AWG)]
4, 4, 4 (12, 12, 12) (min. 0.2 (24))
IP55, IP66 max. cable cross-section (line power, motor,
brake and load sharing) [mm
2
(AWG)]
4, 4, 4 (12, 12, 12)
Max. cable cross-section with disconnect 6, 4, 4, (10, 12, 12)
Line Power Supply 3 x 200-240 V AC - Normal overload 110% for 1 minute
Adjustable frequency drive
Typical Shaft Output [kW]
P5K5
5.5
P7K5
7.5
P11K
11
P15K
15
P18K
18.5
IP20, IP21 max. cable cross-section (line power, motor,
brake and load sharing) [mm
2
(AWG)]
10, 10 (8,8-) 35,-,- (2,-,-) 35 (2) 50 (1)
IP21, IP55, IP66 max. cable cross-section (line power,
motor) [mm
2
(AWG)]
10, 10 (8,8-)
35, 25, 25
(2, 4, 4)
50 (1)
IP21, IP55, IP66 max. cable cross-section (brake, load
sharing) [mm
2
(AWG)]
16, 10, 16 (6, 8 ,6) 35,-,- (2,-,-) 50 (1)
Line Power Supply 3 x 200-240 V AC - Normal overload 110% for 1 minute
Adjustable frequency drive
Typical Shaft Output [kW]
P22K
22
P30K
30
P37K
37
P45K
45
IP20, IP21 max. cable cross-section (line power, motor,
brake and load sharing) [mm
2
(AWG)]
150 (300 MCM)
IP21, IP55, IP66 max. cable cross-section (line power,
motor) [mm
2
(AWG)]
150 (300 MCM)
IP21, IP55, IP66 max. cable cross-section (brake, load
sharing) [mm
2
(AWG)]
95 (3/0)
Line Power Supply 3 x 380-480 V AC - Normal overload 110% for 1 minute
Adjustable frequency drive
Typical Shaft Output [kW]
P1K1
1.1
P1K5
1.5
P2K2
2.2
P3K0
3
P4K0
4
P5K5
5.5
P7K5
7.5
Typical Shaft Output [HP] at 460 V 1.5 2.0 2.9 4.0 5.0 7.5 10
IP20, IP21 max. cable cross-section (line power, motor,
brake and load sharing) [mm
2
(AWG)]
1)
4, 4, 4 (12, 12, 12)
(min. 0.2 (24))
IP55, IP66 max. cable cross-section (line power, motor,
brake and load sharing) [mm
2
(AWG)]
1)
4, 4, 4 (12, 12, 12)
Max. cable cross-section with disconnect 6, 4, 4 (10, 12, 12)
