17.1.1 Line Power Supply 3 x 525-690 V AC
Table 18: Line Power Supply 3 x 525-690 V AC
Table 19: Line Power Supply 3 x 525-690 V AC IP20-Chassis/IP21-IP55/NEMA 1-NEMA12
Table 20: Line Power Supply 3 x 525-690 V AC IP21-IP55/NEMA 1-NEMA 12
1)
American Wire Gauge
17.2 Connection Tightening Torques
Table 21: Tightening of Terminals
1)
For different cable dimensions x/y, where x <= 0.147 in
2
[95 mm
2
] and y >= 0.147 in
2
[95 mm
2
].
Normal overload 110% for 1 minute
Adjustable frequency drive
Typical Shaft Output [kW]
P1K1
1.1
P1K5
1.5
P2K2
2.2
P3K0
3
P4K0
4
P5K5
5.5
P7K5
7.5
IP20 max. cable cross-section (line power, motor, brake
and load sharing) [mm
2
]/(AWG)
[0.2-4]/(24-10)
Normal overload 110% for 1 minute
Adjustable frequency drive
Typical Shaft Output [kW]
P11K
11
P15K
15
P18K
18
P22K
22
P45K
45
P55K
55
Typical Shaft Output [HP] at 575V 16.4 20.1 24 33 60 75
Max. cable size (line power, motor, brake) [mm2]/(AWG)
1)
[35]/(1/0) [50]/(1)
Normal overload 110% for 1 minute
Adjustable frequency drive
Typical Shaft Output [kW]
P30K
30
P37K
37
P45K
45
P55K
55
P75K
75
Typical Shaft Output [HP] at 575V 40 60 60 75 100
Max. cable size (line power, motor, brake) [mm2]/(AWG)
1)
[95]/(4/0)
Power (kW) Torque (Nm)
Enclosure
200-240
V
380-480/
500 V
525-600 V 525-690 V
Line
Power
Motor
DC
Connection
Brake Ground Relay
A2 1.1-2.2 1.1-4.0 0.6 0.6 0.6 1.8 3 0.6
A3 3.0-3.7 5.5-7.5 1.1-7.5 1.1-7.5 0.6 0.6 0.6 1.8 3 0.6
A4 1.1-2.2 1.1-4.0 0.6 0.6 0.6 1.8 3 0.6
A5 1.1-3.7 1.1-7.5 1.1-7.5 0.6 0.6 0.6 1.8 3 0.6
B1 5.5-11 11-18 11-18 1.8 1.8 1.5 1.5 3 0.6
B2 15 22-30 22-30 11-30 4.5 4.5 3.7 3.7 3 0.6
B3 5.5-11 11-18 11-18 1.8 1.8 1.8 1.8 3 0.6
B4 15-18 22-37 22-37 11-37 4.5 4.5 4.5 4.5 3 0.6
C1 18-30 37-55 37-55 10 10 10 10 3 0.6
C2 37-45 75-90 75-90 37-90
14/24
1)
14/24
1)
14 14 3 0.6
C3 22-30 45-55 45-55 45-55 10 10 10 10 3 0.6
C4 37-45 75-90 75-90
14/24
1)
14/24
1)
14 14 3 0.6
