Taie FU96 - Output Calibration Procedure Diagram; Output Calibration Steps

14.6 Output Calibration Steps
1. Display CLO1 & CHO1：
PV / SV monitor
Enter to Level 2
show P1
PV
press
key 3 seconds
PV
press key switching to
PV
SV SV
display＂LCK ＂
SV
LCK setting to 1111
Enter to Level 4 SET4 X is
show SET1 current value
PV press + VP ot gnihctiws yek sserp VPsdnoces 3 yek
SV SV
display＂SET4 ＂
SV
XXX
SET4_4= 1
open CLO1 、 CHO1
if SET4_4 setting finish
PV
press + key 3 seconds , return to PV / SV monitor
SV XXX
※ : X is default value which does not need to be modified
2. Adjust CLO1 low-point calibration value :
SV = LSPL Enter to Level 3
Minimum output show INP1
ot gnihctiws yek sserpVPsdnoces 3 yek + sserp VP PV
SV SV
display＂CLO1 ＂
SV
adjust CLO1 until
meter = 4mA
PV
if CLO1 setting finish
SV
press + key 3 seconds , return to PV / SV monitor
※ : CLO1 calibration value of each controller is different from the other
3. Adjust CHO1 high-point calibration value
SV = USPL Enter to Level 3
Maximum output
show INP1
PV press + ot gnihctiws yek sserp VPsdnoces 3 yek PV
SV SV
display＂CHO1 ＂
SV
adjust CHO1 until
meter = 20mA
hsinif gnittes 1OHC fi VP
SV
press
+ key 3 seconds , return to PV / SV monitor
※ : CHO1 calibration value of each controller is different from the other
