3. Specifications
Model FY400/FU400/48 FY600 FY700/FU72 FY800/FU86 FY900/FU96
Supply Voltage AC 85 ~ 265V, DC 24V (Optional Functions)
Power Frequency 50/60 Hz
Power Consumption Approximately 6VA
Memory Non-Volatile Memory EEPROM
Cold
j
unction compensation diode external
Accuracy : 0.1%
Cold
j
unction compensation diode internal
Sensor Input
Accuracy : 0.3%
Sample time : 50ms
※ Please refer to Input
Thermalcouple: (K、J、R、S、B、E、N、T、W、PLⅡ、L)
Range Table RTD: PT100
DC Linear Analog Input: 0~20mA、4~20mA
0~1V、0~5V、0~10V、0~2V、1~5V、2~10V
0~25mV、0~50mV、0~70mV
1a 1c 1c 1c 1c
OUT1 Rela
y
1a SPST-NO, 250 VAC, 5A
(
resistive load
)
, electrical life: 100,000 operations
1c SPDT-NO, 250 VAC, 5A (resistive load), electrical life: 50,000 operations
Output
SPDT-NC, 250 VAC, 2A (resistive load), electrical life: 20,000 operations
OUT2 Relay SPST-NO, 250 VAC, 5A (resistive load), electrical life: 100,000 operations
SSR Driver ON: 24 V OFF: 0V max. load current: 20mA, with short circuit protection circuit
linear 4~20mA,0~20mA, 0~5V,0~10V, 1~5V,2~10V
Control Method
ON-OFF or P、PI、PID control
1a 1c 1a 1c 1c
Alarm 1 1a SPST-NO, 250 VAC, 5A (resistive load), electrical life: 100,000 operations
1c SPDT-NO, 250 VAC, 5A (resistive load), electrical life: 50,000 operations
Alarm
SPDT-NC, 250 VAC, 2A (resistive load), electrical life: 20,000 operations
Alarm 2 SPST-NO, 250 VAC, 5A (resistive load), electrical life: 100,000 operations
Alarm 3
--- 1a 1a 1a 1a
SPST-NO, 250 VAC, 5A (resistive load), electrical life: 100,000 operations
Re-transmitted
4~20mA、0~20mA、0~5V、0~10V、1~5V、2~10V
Signal
TRS
Source of Re-
SV、PV
transmission
Accuracy 0.1%
Resolution 14 bit
Remot
Signal
4~20mA、0~20mA、0~5V、0~10V、1~5V、2~10V
Resolution 18 bit
e SV
controlled by SV
Motor
Signal
1KΩ、560Ω
Resolution 18 bit
valve
controlled by PV2
Interface RS-485 Half duplex Communication MAX. 31 units, MAX. distance 1200 meters
Protocol Modbus RTU , TAIE
Comm Parity bit NONE, ODD, EVEN
unicati
Data bit 8 bit on
Stop bit 1 or 2 bit
Baud rate 2400,4800,9600,19200,38400,57600,115200 bps
O
p
eratin
g
Environment
0 ~ 50°C (in the case of no freezing or condensatioin) / 20% ~ 90% RH
Temperature/Humidity
Stora
g
e Environment
-25 ~ 65°C (in the case of no freezing or condensatioin)
Temperature
Dimension (mm)
W48 x H48 x D95 W96 x H48 x D95 W72 x H72 x D95 W48 x H96 x D95 W96 x H96 x D95
weight Appox.120g Appox.170g Appox.150g Appox.170g Appox.230g
5 FY/FU operation manual
