SetMaskColor
Set color of masks.
Command
Command Packet
H
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
SetMaskColor
8x
01
04
78
0p
0p
0p
0p
qq
rr
FF
2 out of 14 colors can be selected as mask color. The color of each mask is decided by
mask bit setting of 1/0. It becomes a color code qq by setting 0, and it becomes a color
code rr by setting 1.
The relation of mask/bit position and pp are the same as Display section.
Set a color of each mask with this command before turning on the Display.
0p 0p 0p 0p: Mask bit
0p
0p
0p
0p
Bit
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
7
6
5
4
3
2
1
0
Mask
-
-
-
-
-
-
7
6
-
-
-
-
-
-
5
4
-
-
-
-
-
-
3
2
-
-
-
-
-
-
1
0
qq, rr: Color Code
Mask(Color)
Code(qq,rr)
Mask(Color)
Code(qq,rr)
Black
00h
White
07h
Gray1
01h
Red
08h
Gray2
02h
Green
09h
Gray3
03h
Blue
0Ah
Gray4
04h
Cyan
0Bh
Gray5
05h
Yellow
0Ch
Gray6
06h
Magenta
0Dh
