ppp: Pan Angle, qqq: Tilt Angle, rrrr: Zoom Position
Non_InterlockMask
Set a mask that does not link to Pan/Tilt movement but link to Zoom movement.
As for the value of x, y, w, and h, please refer to the explanation of the parameter in
the above command list.
Setting orders
1. Select color by SetMaskColor command. Choose 2 of 14 colors and set the color in
each mask.
2. Move and face the camera to the target by setting SetPanTiltAngle. Zoom level is
set by zoom command.
3. Execute SetMask.
4. Set mask on or off by Display command. 1=On 0=Off on the value p.
5. Set the mask size with some margin to cover an error range. Make sure the target
is covered or not by moving the camera.
6. The set up condition will be gone when turn off the power. To keep the set up
condition Custom pre-set is recommended.
