9 HARDWARE CONFIGURATION (GENERL INFORMATION)
To avoid shipping very long products, QFlex products are modular, so it will be possible to assemble the components of a
QFlex product on site. Each QFlex module incorporates a mains power supply, DSP platform with VNET support, and
audio amplication.
All of the required joining hardware and bracketry is included with each QFlex purchase. If you have purchased a QFlex
8 or a QFlex 16 there are no connecting plates or other joining hardware. Each QFlex carton is marked to show each
modules position in the array.
QFlex modules must only be joined or separated with the complete column laying at on the ground and disconnected
from the mains supply.
There are 5 individual modules that make up the complete QFlex Range:
a. 8 channel master unit (80014910)
b. 8 channel slave unit (8001 4900)
c. 16 channel master unit (8001 4890)
d. 16 channel slave unit (top) (8001 4880)
e. 16 channel slave unit (bottom) (8001 4870)
