Tannoy Qflex

10.4 WALL BRACKET MOUNTING CENTRES - QFLEX 24 & QFLEX 32
QFlex must be wall mounted with the separately ordered mounting kit. The Wall bracket should be tted to the wall rst.
When you are satised with the mounting locations, x the bracket to the wall using the instructions supplied with the
bracket and ensuring that the installation complies with all local regulations.
QFlex 24
QFlex 32
52.0
(2.05”)
744.5
(29.31”)
537.0
(21.14”)
329.5
(12.87”)
64.5.
(2.54”)
64.5
(2.54)
52.0
(2.05”)
233.5
(9.19”)
441.0
(17.36”)
648.5
(25.83”)
