18 SPECIFICATIONS

QFlex 8 QFlex 16 QFlex 24

Conguration

4” LF 8 8

3” LF 8 8

1” HF 8 8

No. of Amp Channels

100W(RMS) @ 4 Ohms 8 16 24

Vertical Dispersion Variable between 10 - 100 degrees (Asymmetric & multiple beams may also be generated)

Frequency Range 110Hz - 4kHz 130Hz - 20kHz 110Hz - 20kHz

Horizontal Dispersion 120 degrees 120 degrees 120 degrees

Aiming Angle Limit +/- 70 degrees +/- 70 degrees +/- 70 degrees

LF Beam Control Limit 700Hz 700Hz 400Hz

Maximum SPL @ 100ft (30m)* 92dB 94dB 96dB

Column Height 840mm (33”) 744mm (29.3”) 1483mm (58.4”)

Column Width 171.5mm (6.7”) 171.5mm (6.7”) 171.5mm (6.7”)

Column Depth 150mm (5.9”) 150mm (5.9”) 150mm (5.9”)

Typical Application Distance** 20m (66ft.) 25m (82ft.) 40m (131ft.)

Sample Rate 96kHz 96kHz 96kHz

Audio Inputs Analogue & AES/EBU Analogue & AES/EBU Analogue & AES/EBU

Weight inc hardware 15.25kg (33.6 lbs) 14.25kg (31.4 bs) 26.25kg (58.4 lbs)

* Average SPL (1kHz – 8kHz). Based on a mounting height of 10m (33ft) and a target area @ 30m (98.5ft) and 10m (33ft) wide. Maximum

attainable SPL is dependant on the dimension of the target area(s). Exact gures can be derived in the BeamEngine™ programme.

** Based on the above venue criteria achieving 95dB SPL at the quoted distance.
