10.2 WALL BRACKET MOUNTING CENTRES - QFLEX 8 & QFLEX 16
QFlex must be wall mounted with the separately ordered mounting kit. The Wall bracket should be tted to the wall rst.
When you are satised with the mounting locations, x the bracket to the wall using the instructions supplied with the
bracket and ensuring that the installation complies with all local regulations.
QFlex 8
QFlex 16
64.5
(2.54”)
648.5
(25.53”)
441.0
(17.36”)
52.0
(2.05”)
233.5
(9.19”)
744.5
(29.31”)
537.0
(21.14”)
329.5
(12.97”)
64.5.
(2.54”)
52.0
(2.05”)
