10.7 QFLEX 48 ASSEMBLY
It is recommended that you assemble the column horizontally on a at surface. Lay some cloth or cardboard on the
surface to avoid scratching the surface of the product during the assembly process.
In the hardware pack you will nd two wall brackets and joining hardware consisting of two heavy joining plates with
hinge points, one heavy joining plate, six small link bars and M4 Phillips screws.
Place each module in its respective position on the assembly area keeping them slightly spaced apart. Take the ying
RJ45 connector in the rst (bottom) module and insert it into the RJ45 socket in the second module. Take the ying
AC mains connector in the rst (bottom) module and insert it into the female connector in the second module. Take the
ying RJ45 connector in the second module and insert it into the RJ45 socket in the third module. Take the ying AC
mains connector in the second module and insert it into the female connector in the third module. Take the ying RJ45
connector in the third module and insert it into the RJ45 socket in the fourth (top) module. Take the ying AC mains
connector in the third module and insert it into the female connector in the fourth (top) module.
Align the four columns together as shown below.
The wall brackets can be hinged on the left or right pivot points. 3mm Allen grub screws allow the QFlex 40 to be locked
at the desired horizontal angle. The installer must ensure that the mounting surface is capable of safely and securely
supporting the loudspeaker. Seek help from architects, structural engineers or other specialists if in any doubt.
Note: The hinge plate without
the pivot points must be installed
between columns 3 & 4.
STAGE 2
STAGE 1
STAGE 3
STAGE 2
STAGE 1
STAGE 3
CAT 5
POWER CORD
Attach the joining plates between
each module in the three stages as
shown.
To Next Page
