6
TASCAM Model 24
1 – Introduction
Thank you very much for purchasing the TASCAM Model 24 Analog
Mixer.
Before using this unit, read this Owner's Manual carefully so that you will
be able to use it correctly and enjoy working with it for many years. After
you have finished reading this manual, please keep it in a safe place for
future reference. You can also download this Owner’s Manual and the
Reference Manual from the TEAC Global Site (http://teac-global.com/).
Features
0
22 input analog mixer with 22 line and 16 mic inputs
0
Multitrack recording and playback with 24-track recording (22 input
channels and MAIN MIX L/R bus)
0
USB audio interface functions built-in
o
24 tracks (22 input channels and MAIN MIX L/R bus) can be input
to the computer
o
22 track outputs and computer outputs can be assigned to chan-
nel inputs
o
Supports USB 2.0 at up to 48kHz and 24-bit
0
Compressors included on channel 1-12 inputs
0
100mm faders enable precise adjustments
0
High impedance (Hi-Z) inputs on channels 1-2
0
Channel inserts (INSERT) on channels 1-2
0
Multiple buses include stereo main (MAIN MIX L/R bus), sub (SUB L/R
bus) and monitor (MONITOR OUT 1/2)
0
3 AUX sends (MON 1/MON 2/FX)
0
Input channels have 3-band semi-parametric EQs with adjustable
mid frequencies
0
Outputs have a 7-band stereo graphic EQs useful for adjusting the
mix
0
16 TASCAM preset effects can be used for a variety of applications
0
Multitrack recording and playback possible using SD cards
0
Bluetooth® audio playback supported
0
Punching in and out supported per track (including punching in and
out automatically and with footswitches)
0
SD/SDHC cards and SDXC cards up to 128GB supported
Included items
This product includes the following items.
Take care when opening the package to avoid damaging the items. Keep
the box and packing materials for transportation in the future.
Please contact the store where you purchased this unit if any of these
items are missing or have been damaged during transportation.
0
Main unit ...............................................................................................................× 1
0
Power cord ...........................................................................................................× 1
0
Owner's Manual (this document) including warranty ......................... × 1
Conventions used in this manual
In this manual, we use the following conventions:
0
When we refer to a button or connector or control on the DR-40, the
typeface looks like this: MENU.
0
When we show characters that appear on the display, the typeface
looks like this: MENU.
0
The four buttons under the display are called the function buttons.
From left to right, they are shown as buttons F1, F2, F3 and F4.
Moreover the functions show at the bottoms of the screens will be
shown in parentheses after the button names.
Examples: F1
button, F4 button
0
SD/SDHC/SDXC memory cards are referred to as “SD cards”.
0
Computers, portable audio devices and other equipment connected
to this unit using Bluetooth are called "Bluetooth devices".
0
The song that is currently selected is called the “current song”.
0
Additional information is introduced in the styles below when
needed:
TIP
We give hints and tips on using the DR-40 when you see this icon.
NOTE
These provide additional explanations and describe special cases.
CAUTION
Failure to follow these instructions could result in damage to equip-
ment or lost data, for example.
V
CAUTION
Failure to follow these instructions could result in injury.
