TC Electronic FLASHBACK X4 User Manual

9
Audio inputs and outputs
1 – Audio inputs and outputs
1
The Flashback X4 Delay & Looper is equipped with ¼" input and
output jacks.
Audio inputs
– If your signal source is mono, connect it to the INPUT MONO
jack.
– If your signal source is stereo, connect the cable carrying the
left signal component to the INPUT MONO jack and the cable
carrying the right signal component to the INPUT –STEREO jack.
Audio outputs
– If the next device in the signal chain has a mono input, connect
the Flashback X4 Delay & Looper’s OUTPUT MONO jack to the
other device’s input.
– If the next device in the signal chain has stereo inputs, connect
the Flashback X4 Delay & Looper’s OUTPUT MONO jack to the
left input and the OUTPUT –STEREO jack to the right input of
the device.
“So how do I configure the Flashback X4 for mono or
stereo operation? What if I want mono input and stereo
out or…”
“Stop worrying – start rocking!”
You don’t need to worry about mono/stereo configuration issues.
The Flashback X4 Delay & Looper uses auto-sensing technology
to detect if you are using it in mono or stereo – both on inputs
and outputs.

TC Electronic FLASHBACK X4 Specifications

General

Looper	Yes (40 seconds)
Presets	3
Tap Tempo	Yes
MIDI	Yes
TonePrint	Yes
Current Draw	300 mA
Type	Delay
Inputs	2 x 1/4"
Outputs	2 x 1/4"
Power Source	9V DC
Delay Types	2290, Analog, Tape
True Bypass	Yes (switchable to buffered)
