TC Electronic FLASHBACK X4 User Manual

13
Delay type selector
6 – Delay type selector
6
Use the DELAY TYPE SELECTOR to choose the type of delay you
want to work with. The Flashback X4 Delay & Looper offers a
wide range of delays – from classic tape delays to the pristine
sound of a TC 2290.
The delay types are described on page 7.
When you choose a delay type, the chosen delay type will “pick
up” the current positions of the delay control knobs (for example
DEL AY TIME). However, if you choose a preset and turn one of the
delay control knobs, nothing will change except for that one, spe-
cific parameter.
The slots “1”, “2”, “3” and “4” of the Delay Type Selector are
“placeholders” for TonePrints. The Flashback X4 Delay & Looper
comes equipped with the following default TonePrints:
– Delay TonePrint by Steve Morse
– Basic Delay TonePrint by Bumblefoot
– Basic Delay TonePrint by Doug Aldrich
– Synth Delay by James “Munky” Shaffer
The TonePrint concept is explained in detail on page 14.

TC Electronic FLASHBACK X4 Specifications

General

Looper	Yes (40 seconds)
Presets	3
Tap Tempo	Yes
MIDI	Yes
TonePrint	Yes
Current Draw	300 mA
Type	Delay
Inputs	2 x 1/4"
Outputs	2 x 1/4"
Power Source	9V DC
Delay Types	2290, Analog, Tape
True Bypass	Yes (switchable to buffered)
