DC Inverter Air
Wooden construction
Put the square timber over the roof beam，t hen install the hanging
screw bolt .
New concrete bricks
Inlaying or embedding the screw bolt
Timber over the beam
Roof be am
Ceilin g
Hanging screw bolt
(Blade shape insertion )
Finished concrete bricks
In stall the ha nging ho ok with exp ans ble
bo lt in to th e con cre te de e p t o 45-50m m t o prevent loo se.
(Slide insertion)
Hanging bolt
Steel roof bea m structure
Make use of steel in the ceiling or supporting angle steel..
Hanging bolts Supporting angle steel
2) Hanging &Installation of Indoor Unit
Adjust the nut position while the gap between gasket(downside) and ceiling should be confirmed acc
ording to actual situations.
32/ 113
