TCL TCA-60HRA/DV3O User Manual

DC Inverter Air
8. Design and Installation of Connecting Pipes
8.1. Pipe length and drop height shall comply with the scope required below.
Mode
18K
24K
Max pipe length
30m
35m
Max drop height l
15m
20m
Max bending No.
5
5
The refrigerant shall be
increased while the
22g/m
65g/m
mounted pipe is more
than the standard piping
Mode
36K
48K
60k
Max pipe length
50m
50m
50m
Max drop height l
30m
30m
30m
Max bending No.
5
5
5
The refrigerant shall be
increased while the
50g/m
50g/m
50g/m
mounted pipe is more
than the standard piping
Note: A return oil elbow must be equipped for each drop of 10m in the vertical height of
refrigerant pipe!
Connection Mode
Gas Side
Liquid Side
Outdoor Unit
Flare nut
Flare nut
Indoor Unit
Flare nut
Flare nut
8.2. Material and Size of the Pipes
Outdoor pipe dimension and installation modes (in sequence of cooling capacity)
Pipe material
Copper Pipe For Air Conditioner
Model
18‐‐22K
23‐‐28K
30‐‐48K
49‐‐60k
Size(mm)
Liquid side
Φ6.35(1/8inch)
Φ9.52(3/8inch)
Φ9.52(3/8inch)
Φ9.52(3/8inch)
Gas side
Φ12.7(1/2inch)
Φ15.88(5/8inch)
Φ19.05(3/4inch)
Φ19.05(3/4inch)
67/ 113
