TCL TCA-60HRA/DV3O User Manual

DC Inverter Air
M ODE
A
B
C
D
E
F
H
R EMA RK
1 8
7 80
5 2 1
29 0
3 28
2 90
2 88
6 05
Fig .1
2
4
9 00
7 5 3
34 9
3 99
3 15
3 04
6 50
Fig .1
3
6
9 40
6 0 0
37 5
4 00
3 40
33 8
8 85
Fig .1
4 8
/6 0
9 40
6 0 0
37 5
4 00
3 40
3 38
1 2 50
Fig. 2
6. Installation Requirements of Outdoor Unit
1. Hoisting and Transportation of Outdoor Unit
 Please use four wire ropes of at least Φ6mm to hoist the outdoor unit and pay attention to the
gravity center position to avoid the slide and turnover of the outdoor unit, and forklift can also be
used for the handling;

 Please add the guard plate at the contacting surface between wire rope and air conditioner to avoid
the surface scratches and deformation of the outdoor unit;

 Please remove the backing plate for transportation after completing the hoisting operations, as
shown in the following figures:
Steel wire
G u a r d
Steel wire
G u a r d
2. Installation Site of Outdoor Unit
Do not install the outdoor unit in the following places:
59/ 113
