TCL TCA-60HRA/DV3O User Manual

DC Inverter Air
Coil length * height *
mm
776×570.5×36.4
896×611×36.4
width
Number of circuits
3
5
Fan System
Outlet size of indoor airflow
mm
/
/
Outdoor fan type
Propeller
Propeller
Connections
Connecting
Liquid
mm
6.35
9.52
Pipe
Gas
mm
12.7
15.88
Max. height drop (high head)
m
15
20
Max. length of connecting pipe
m
30
35
Refrigerant charge with long pipe
g/m
22
50
Drainage Pipe
mm
Others
Net dimensions
Outdoor
mm
780×605×290
900×650×310
(W x H x D)
Net weight
Outdoor
kg
33
52
Packing
dimensions
Outdoor
mm
883×653×412
1015×720×425
(W x H x D)
Gross weight
Outdoor
kg
36
57
Loading
Capacity
Note
Specifications are based on the following conditions:
Cooling: Indoor temperature 27℃ DB/19℃WB,and outdoor temperature
35℃ DB/24℃ WB.
Heating: Indoor temperature 20℃ DB/15℃WB,and outdoor temperature 7℃ DB/6℃ WB.
Voltage:22V.
Sound Level: Indoor unit sound pressure level,measured at a point 1.5m downward from the unit center.
Outdoor unit sound pressure level,measured at a point 1.0m in front of the unit.
Optional simple wired controller; Universal remote controller; auto‐restart(optional); Timer:only one circle.
Due to ongoing product development, specifications are subject to change without notice.
54/ 113

TCL TCA-60HRA/DV3O Specifications

General

Brand	TCL
Model	TCA-60HRA/DV3O
Category	Air Conditioner
Language	English
