TCL TCA-60HRA/DV3O User Manual

DC Inverter Air
MODEL
36K
48K
60K
INDOOR
PHASE
1‐PHASE
3‐PHASE
3‐PHASE
UNIT
FREQUENCY AND VOLT
220‐240V 50Hz
220‐240V 50Hz
220‐240V 50Hz
POWER
POWER WIRING (MM
2
)
3*2.5
3*2.5
3*2.5
CIRCUIT BREAKER (A)
15
15
15
OUTDOOR
PHASE
1‐PHASE
3‐ PHASE
3‐ PHASE
UNIT
FREQUENCY AND VOLT
220‐240V 50Hz
380V 50Hz
380V 50Hz
POWER
POWER WIRING (MM
2
)
3*4.0
4*4.0
4*4.0
CIRCUIT BREAKER (A)
30
30
30
INDOOR/OUTDOOR CONNECTION
3*0.75
3*0.75
3*0.75
WIRING(WEAK ELECTRIC SIGNAL((MM
2
)
INDOOR/OUTDOOR CONNECTION
3*2.5
3*2.5
3*2.5
WIRING(STRANG ELECTRIC SIGNAL((MM
2
)
Notes:
1) The diameter of power capacity cables and power cables shall be selected according to the requirements, and the diameter of
air‐condition power cord shall be greater than that of common power cord;
2) In order to prevent the misuse of the air conditioner, it is necessary to make sure of no staggering and winding of
power cord with the connection line of the indoor unit;
3) After the airtight test and the vacuum pumping operation, it shall be energized;
4) The signal cables of the control system and the power cords shall not be placed in the same conduit and there shall be a
proper spacing between two conduits;
5) The connection signal lines between indoor units and between indoor unit and outdoor unit must be subject to a uniform
system installation with the refrigerant piping;
6) There shall be no intermediate transition joint for the shielded cables.
63/ 113
