1. BATTERY AND CHARGER
- 1 -
1. BATTERY AND CHARGER (OPTION)
The description in this section applies to our optional batteries and chargers. For other types of
batteries and chargers, refer to their respective instruction manuals. The description of the VTM unit
applies to all the trucks because the VTM unit is standard equipment.
Truck model
FB10-7
FB15-7
FB20-7 FB25-7
Item FB18-7
Battery
Capacity 330AH/5h 400AH/5h 450AH/5h 565AH/5h
Name VSDX330M VSDX440M VSDX450M VSDX565HM
Voltage 48 V
Specic gravity of
electrolyte 1.280
Weight 650 kg 695 kg 830 kg 915 kg
Charger
Type Truck-mounted type, 3-phase AC semiconstant voltage charger
Rated power 6.0 kVA 8.5 kVA
Rated current 17 A 24 A
Power supply voltage 380 / 440 V
Applicable battery
capacity 320 - 500 AH/5h 450 - 700 AH/5h
Output
Voltage 51 - 64 V
Current 80 - 20 A 115 - 29 A
Truck model
FB25-7LB FB25-7V
FB30-7
FB35-7S
Item FB30-7V
Battery
Capacity 935AH/5h 865AH/5h 450AH/5h 545AH/5h
Name VSF935 VSF865 VSDX450MZ VSDX545MH
Voltage 48 V 72 V
Specic gravity of
electrolyte 1.280
Weight 1450 kg 1350 kg 1130 kg 1285 kg
Charger
Type
Truck-mounted type, 3-phase AC semiconstant voltage charger
Rated power 12 kVA
Rated current 34 A
Power supply voltage 380 / 440 V
Applicable battery
capacity 320 - 500 AH/5h 450 - 700 AH/5h
Output
Voltage 51 - 64 V 76.5 - 96 V
Current 160 - 40 A 105 - 26 A
