2. SPECIFICATION
2.1. Average Charging Power
8,000 Joules/sec (½CV
2
x Rep Rate)
2.2. Peak Charging Power
9,000 Joules/sec (½CV
2
∕ t
charge
)
2.3. Average DC Power
8,000 Watts
2.4. Output Voltage Range
1, 2, 4, 5, 10, 15, 20, 30, 40, 50kV, variable from 10-100% of rated.
Other voltages on request, please contact the factory.
2.5. Polarity
Available as fixed Positive or Negative. Please specify at time of ordering
2.6. HV Output Cable
1-39kV Models - DS2124 Coaxial cable with proprietary HV connector
40-50kV Models - DS2214 Coaxial cable with proprietary HV connector
2.7. HV Insulating Medium
Exxon Mobil Univolt N61B or equivalent insulating oil
2.8. AC Input Voltage
200-240VAC (180-264), 3Ø or 380-440VAC (340-460), 3Ø + N, 50-60Hz
Please specify at time of ordering
2.9. AC Input Current
40A for 200-240VAC Input / 25A for 380-440VAC input
2.10. AC Connector
UL/CSA approved terminal block. 3Ø + GND for 200-240VAC, 3Ø + N +
GND for 380-440VAC
2.11. AC Line Contactor
UL/CSA approved AC line contactor (standard on 802L and 802S, option for
802OEM)
2.12. Power Factor
Passive PFC pf = 0.85 at full load and nominal AC line
2.13. Efficiency
Better than 85% at full load
2.14. Front Panel
802L - Voltage Control, Voltage & Current Meters, Status Indicators
802S - On/Off Switch, Status Indicators
802-OEM - Blank front panel
2.15. Stability
0.2% per hour after 1 hour warmup
2.16. Temperature Coefficient
100ppm per °C typical
2.17. Stored Energy
Less than 0.3J all models
2.18. Pulse to Pulse Repeatability
±2% to 1000Hz, consult factory for higher rep rates
2.19. Dimensions - inches (mm)
19 (483) W x 8.75 (222) H x 17 (432) D
2.20. Weight - lbs (kg)
80 (37)
2.21. Ambient Temperature
Storage: -20 to +70°C. Operating: -20 to +45°C
2.22. Altitude
Storage: 40,000ft (12,000m), Operating: 9,900ft (3,000m)
2.23. Humidity
10-90%, non-condensing
2.24. Protection
Open/short circuits, Overloads, Arcs, Overtemp, Overvoltage, Safety
Interlock
2.25. Remote Control (all models)
Via 25-pin D-sub connector on rear of unit, Signals include, Vprogram (0-
10V), HV Enable/Reset, Inhibit, Summary Fault, Load Fault, Vanalog, Vpeak
2.26. Accessories
10ft HV cable, operating manual
