5.17. Rear Panel Layout (OEM Models)
The 802OEM rear panel is similar to the 802S except there is no interlock terminal, unless
the CT option is installed. If a number of units are to be connected in parallel, a daisy chain
type ribbon cable should be used to connect the supplies together. See section 6.4 for more
details.
Note:
The numbers in Figure 10 refer to Table 5.
!
L1 L2 L3 N
Figure 10 802OEM Rear Panel
1
2
4
5
6
9
