SUPPLY CONFIGURATIONS
Local Control Supply may be run from front panel even if LAN is monitoring
LAN Remote Control Supply may be controlled and monitored through LAN
RS-232/485 Control LAN may be disabled to use the standard RS-232/485 ports
‘J1’ Analog Control LAN may monitor supply while analog controller sets output
Series / Parallel Supplies Rules for standard Genesys supplies apply to LAN supplies
Advanced Parallel Rules for standard Genesys supplies apply to LAN supplies
INDICATORS
IP and MAC Address View addresses on front panel
Multi-drop Address View RS-485 address on front panel
Link LED Indicates the Ethernet cable connected at both ends
Activity LED Indicates when LAN packets detected
LAN Status LED Red/green, indicates power supply has valid IP connection
Blink Identify Find the supply by remotely blinking front and rear LEDs
Local/Remote LED Indicates if LAN has control of supply output
BUTTONS, SWITCHES
LAN Reset Front panel button
IP Address Change entire IP address on front panel
Multi-drop Address Change RS-485 address on front panel
LAN/ RS Select Disable LAN to enable RS-232/485 or Multi-drop slave
SECURITY
Web Page Password Can set password to prevent unauthorized or accidental changes to LAN
settings
or power supply output settings.
Single Client Only Set to prevent multiple programs from taking control
Block UDP Sockets Single client will block attacks through UDP sockets
Disable VXI-11 Discovery Stop intruders from finding the power supply
Disable Ping Server Stop intruders from finding the power supply
COMPLIANCE
LXI Certified for LXI (rev 1.1) class C instrument
UL, IEC, TUV, Conformances that are granted to basic power supply also apply to power
supply with LAN installed
CE, ROHS etc
