31
OUTPut:TTLTrg:MODE
Parameter
OFF - 0x0000; FSTR – 0x0001; TRIG - 0x0002 as return value.
[PROGram]:COUNter
Parameter INFinity – write 0x0000; Number of iterations - write 1-9999 as parameter. Any
value above 9999 results in INFinity.
[PROGram]:LIST:CURRent
Parameter Each value is loaded into a single register. Refer to Section 9.9 for an example
of Voltage registers.
Upload [PROGram]:LIST:CURRent registers
Specific MODBUS TCP specific command used to upload [PROGram]:LIST:CURRent into
power supply. Refer to Section 9.9 for an example of Voltage registers.
[PROGram]:LIST:DWELl
Parameter Each value is loaded into a pair of registers. Low address value holds the least
significant part. Refer to Section 9.9 for an example.
Upload [PROGram]:LIST:DWELl registers
Specific MODBUS TCP specific command used to upload [PROGram]:LIST:DWELl into
power supply. Refer to Section 9.9 for an example.
[PROGram]:LIST:VOLTage
Parameter
Each value is loaded into a single register. Refer to Section 9.9 for an example.
Upload [PROGram]:LIST:VOLTage registers
Specific MODBUS TCP specific command used to upload [PROGram]:LIST:VOLTage into
power supply. Refer to Section 9.9 for an example.
[PROGram]:STEP
Parameter
ONCE – write 0x0000; AUTO - write 0x0001 as parameter.
[PROGram]:WAVE:CURRent
Parameter Each value is loaded into a single register. Refer to Section 9.9 for an example
of List Voltage registers.
Upload [PROGram]:WAVE:CURRent registers
Specific MODBUS TCP specific command used to upload [PROGram]:WAVE:CURRent
into power supply. Refer to Section 9.9
for an example of LIST Voltage
registers.
