(1)
Reel
Turntable
Provides
a
platform
for
the
tape
reels.
(See
pg.
9.)
(2)
Quik-Lok
Reel
Holders
Firmly
hold
tape
reels
to
the
turntables.
(See
pg.
9.)
(D
Tape
Tension
Arm
Acts
as
a
mechanical
filter
with
the
Tape
Guide
Post
®
to
maintain
proper
tape
tension.
(4)
Index
Counter
Indicates
relative
location
of
selections
on
the
tape.
(5}
Index
Counter
Reset
button
Restores
the
Counter
to
“0000”
(6)
Tape
Guide
Post
(7)
POWER
switch
Depress
to
apply
electrical
power.
Meter
lamps
will
illuminate.
Push
again
for
OFF.
^8
Reel
Size
Selector
Switch
Automatically
adjusts
motor
torque
and
holdback
tension
for
the
size
reel
used.
(9
SPEED
Selector
switch
Controls
tape
speed.
See
pg.
10.
(f(j)
MIC
Input
Level
controls
Regulate
the
recording
levels
from
microphones
or
the
DIN
Socket.
See
pg.
12.
(I
l)
MIC
(L
&
R)
Input
jacks
Accept
the
plugs
from
high
fidelity
microphones
with
an
output
impedance
of
from
150
to
10,000
ohms.
©
LINE
Input
Level
controls
Regulate
the
recording
levels
from
the
LINE
IN
jacks.
©
PHONE
Output
jack
Connection
for
an
8
ohm
stereo
headphones
plug.
©
OUTPUT
Level
controls
Adjust
the
Playback
and
Monitoring
volume
levels.
©
MONITOR
switch
Selects
which
sound
will
be
heard
and
displayed
on
the
Level
Meters,
either
SOURCE
(input)
or
TAPE.
(Pg.
11)
®
Level
Meters
Display
the
relative
recording
or
playback
signal
strength.
@
REC
MODE
switches,
L
and
R
Select
which
channels
(Left
and/or
Right)
will
be
recorded
(ON)
or
not
recorded
(OFF).
©
REC
EQ
and
REC
BIAS
switches
Select
the
proper
Record
Equalization
and
Record
Bias
for
optimum
performance
with
low
noise/high
output
(HIGH)
or
conventional
tapes
(NORMAL).
See
pg.
10.
©
Control
Center
Contains
6
buttons
for
total
control
of
tape
transport
motion
and
Record
activation.
See
pg.
6.
©
Shut-Off
Arm
Removes
electrical
power
from
the
transport
section
if
the
tape
breaks
or
ends.
Also
provides
tape
guidance.
®
Pinch
Roller
Applies
proper
pressure
for
tape
to
be
driven
by
the
capstan.
Engages
only
during
Recording
and
Playback.
@
Capstan
Shaft
Drives
the
tape
at
a
constant
speed
in
the
Play
or
Record
modes.
Rotates
continuously
until
electrical
power
is
removed
from
transport
by
Shut-Off
Arm
or
POWER
switch.
(£$
Head
Housing
Protects
the
tape
heads
from
dust
and
damage.
©
GND
Terminal
Post
Provides
grounding
connection
to
other
components
or
to
earth
ground
if
necessary
to
reduce
hum.
25
)
FUSE
Receptacle
&
Voltage
Selector
Remove
this
cover
to
replace
the
fuse
if
necessary.
Disconnect
the
AC
(mains)
Power
Cord
before
attempt¬
ing
fuse
replacement.
Replace
with
identical
fuse.
(®)
AC
POWER
IN
Connect
to
the
AC
(mains)
wall
outlet.
Deck
is
factory
set
to
voltage
indicated
on
the
rear
panel.
Do
not
connect
this
cord
unless
appropriate
power
is
available.
<g)
REMOTE/TIMER
CONTROL
Dummy
Plug
When
removed,
a
jack
is
provided
for
optional
accessories.
Plug
must
be
installed
for
proper
operation.
See
pg.
22.
©
OUTPUT
R/L
Jacks
Provide
pin
cord
connections
to
an
amplifier
for
listening.
Use
cables
as
provided
in
the
Accessory
Packet.
®
IN/OUT
(DIN)
Socket
Accepts
a
standard
DIN
Cable
for
inputs
and
outputs.
©
LINE
IN
R/L
Jacks
Right
and
Left
channel
inputs
are
connected
to
these
jacks
for
recording.
Use
cables
provided
in
Accessory
Packet.
