Teac MC-D800 User Manual

25
ENGLISH
c3
o If a setting is left for more than 20 seconds, this
time setting mode will end.
4 Press the CLOCK ADJUST button again.
Display example
The “hour” value blinks.
5 Press the TIME (j/k) buttons to set
the current hour.
Setting the clock
Set the current time before using the unit.
1 Press the STANDBY/ON button to put
the unit into standby.
NOTE
The clock can also be set when the unit is on, but
not when the unit is in radio, CD or USB mode.
2 Press and hold the CLOCK ADJUST but-
ton for at least two seconds.
Press and hold for at
least 2 seconds
“SET CLOCK” scrolls across the display.
3 Press the TIME (j /k ) buttons to
switch between 24 HOUR and 12 HOUR
(24-hour or 12-hour time display).
Continued on the next page

Teac MC-D800 Specifications

General

Type	Belt-drive audio turntable
CD player	Yes
MP3 bit rates	8 - 320 Kbit/s
Product color	Black
Wow & flutter	0.35 %
Playback modes	Repeat, Shuffle
Volume control	Rotary
Turntable speeds	45, 78 RPM
FM preset stations	20
Disc types supported	CD, CD-DA, CD-R, CD-RW
Supported radio bands	AM, FM, PLL
Audio formats supported	MP3, PCM, SBC, WMA
Signal-to-Noise Ratio (SNR)	70 dB
USB version	2.0
Bluetooth range	10 m
Bluetooth version	2.1+EDR
Bluetooth profiles	A2DP, AVRCP
USB ports quantity	1
Headphone connectivity	3.5 mm
Impedance	8 Ω
Speaker type	2-way
Frequency range	50 - 20000 Hz
RMS rated power	20 W
Woofer diameter	88.9 mm
Tweeter diameter	38.1 mm
Number of speakers	2
Package depth	500 mm
Package width	610 mm
Package height	320 mm
Package weight	13700 g
Display type	LCD
Power supply type	AC
AC adapter frequency	60 Hz
AC adapter input voltage	120 V

Weight and Dimensions

Weight	6600 g
Product dimensions (WxHxD)	400 x 206 x 386 mm
Satellite speaker dimensions (WxDxH)	144 x 154 x 224 mm
