18
Names and functions of parts (main unit)
A
STANDBY/ON button
Press this button to turn the unit on or put it in
standby.
B
FUNCTION buttons
(PHONO/AUX, FM/AM, CD/Bluetooth/
USB)
Press the PHONO/AUX button to switch between
PHONO and AUX as shown below.
PHONO AUX
To listen to a record, press the PHONO/AUX button
and select “PHONO”.
To listen to a device connected to the auxiliary
input (AUX IN) jacks, press the PHONO/AUX button
and select “AUX”.
Each time you press the FM/AM button, the unit will
switch between FM and AM broadcast reception as
shown below.
FM AM
To listen to an FM station, press the FM/AM button
and select “FM”.
To listen to an AM station, press the FM/AM button
and select “AM”.
Each time you press the CD/Bluetooth/USB button,
the function will change as shown below.
CD Bluetooth USB
To listen to a CD, press the CD/Bluetooth/USB but-
ton and select “CD”.
To listen to a Bluetooth device, press the CD/
Bluetooth/USB button and select “Bluetooth”.
To listen to a USB flash drive, press the CD/Bluetooth/
USB button and select “USB”.
C
PAIRING button
Use this when pairing with other Bluetooth devices
and when ending Bluetooth connections (pages
44 and 43).
D
PLAY MODE button
FM MODE button
When listening to a CD/MP3/WMA file, use to
change the play mode (normal, repeat, shuffle)
(page 38).
When listening to FM radio, use to switch between
stereo and mono (page 49).
Z
K L M N O
P P
