19
ENGLISH
E
Search (m/,) buttons
PRESET (j/k) buttons
Press and hold during CD or MP3/WMA file play-
back to search forward/backward (page 33).
When listening to the radio, use to select preset sta-
tions (page 51).
F
Stop (8) button
Press to stop CD/USB/Bluetooth playback.
G
Play/pause (y/9) button
Press when the CD, USB or a supported Bluetooth
device is stopped or paused to start playback.
Use this button to pause playback during playback.
H
Open/close button (-)
Press to open and close the disc tray.
I
Turntable cover
J
VOLUME knob
Use to adjust the volume. Turn right to raise the
volume and left to lower it.
K
PHONES jack
When you use headphones, first reduce the volume
level to minimum. Then, insert the plug from your
headphones into the PHONES jack, and turn the
volume up gradually by turning the VOLUME knob.
o Do not turn the unit on and put it into standby
or connect and disconnect the headphones
plug while wearing headphones. (Doing so
could cause loud noise to be output from the
headphones.)
o When a plug is in the headphones jack, no sound
will be output from the speakers.
L
Remote control signal receiver
Signals sent from the remote control are received
here. When using a remote, point it toward this
spot.
M
Display
This shows the track number, time, FM/AM fre-
quency and other information.
N
Disc tray
O
Scroll/skip (MULTI JOG/. //j k)
knob
Use when tuning the radio to select stations (page
49).
Use this also to set the current time and the
wakeup timer (pages 25 and 56).
When listening to a CD or USB flash drive, use to
skip to the previous or next track/file (page 33).
P
Right/left speakers
Place the speakers as desired.
