Page #43 background imageLoading...
Page #43 background image
43
ENGLISH
2 Operate the Bluetooth device to start
playback.
If the connected Bluetooth device supports AVRCP,
you can use this unit or the remote control to play,
pause or stop audio on that device.
Depending on the Bluetooth device being used,
remote control operation might not be supported
or actual operations might differ.
o The volume, however, cannot be adjusted remotely.
Audio/Video Remote Control Profile (AVRCP)
To control playback of a Bluetooth device, the
Bluetooth device must support AVRCP.
Some Bluetooth devices, however, have different func-
tions depending on their specifications.
o Depending on the Bluetooth device, skipping
files might not be possible using this units skip
(.//) knob. In this case, use this units search
(m/,) buttons.
o If you cannot control another Bluetooth device with
this unit, operate the other Bluetooth device directly.
Unpairing a device
To unpair with a connected Bluetooth device, press the
PAIRING button.
o If you later want to use a Bluetooth connection with
that Bluetooth device, you must pair them again.
o This deletes all pairing information. Unpairing with
just one device is not possible.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Teac MC-D800 and is the answer not in the manual?

Teac MC-D800 Specifications

General IconGeneral
TypeBelt-drive audio turntable
CD playerYes
MP3 bit rates8 - 320 Kbit/s
Product colorBlack
Wow & flutter0.35 %
Playback modesRepeat, Shuffle
Volume controlRotary
Turntable speeds45, 78 RPM
FM preset stations20
Disc types supportedCD, CD-DA, CD-R, CD-RW
Supported radio bandsAM, FM, PLL
Audio formats supportedMP3, PCM, SBC, WMA
Signal-to-Noise Ratio (SNR)70 dB
USB version2.0
Bluetooth range10 m
Bluetooth version2.1+EDR
Bluetooth profilesA2DP, AVRCP
USB ports quantity1
Headphone connectivity3.5 mm
Impedance8 Ω
Speaker type2-way
Frequency range50 - 20000 Hz
RMS rated power20 W
Woofer diameter88.9 mm
Tweeter diameter38.1 mm
Number of speakers2
Package depth500 mm
Package width610 mm
Package height320 mm
Package weight13700 g
Display typeLCD
Power supply typeAC
AC adapter frequency60 Hz
AC adapter input voltage120 V
Weight and Dimensions IconWeight and Dimensions
Weight6600 g
Product dimensions (WxHxD)400 x 206 x 386 mm
Satellite speaker dimensions (WxDxH)144 x 154 x 224 mm
