Techman Robot TM5 Series - Page 38

I Hardware Installation Manual 4. System Hardware
32
TM5-900 Series Movement Range Diagram
Operator Position
Warning: Risk of crushing
within the operating area of
the arm.
Warning: Risk of collision within
the operating area of the arm.
