Techman Robot TM Palletizing Operator

Questions and Answers

D
Dwayne NguyenAug 14, 2025
How to recover from Emergency Stop on Techman Robot TM Palletizing Operator Robotics?
- S
  Shelly AllenAug 14, 2025
  To recover from an Emergency Stop on your Techman Robot, follow these steps: * First, release all emergency switches. * Next, press the reset button when the button light is on. * Wait 10 seconds for the system to enter Safe Start Up Mode, indicated by a light blue Indication Light Ring. Note that the robot's joints will be without driving power at this stage. * Continuously press the FREE button to release the joint axis brake and allow movement of the robot. * After resolving the issue that caused the emergency stop, press the Stop button on the robot stick or teach pendant for about three seconds. The robot will then calibrate during startup and return to its original operating mode.
J
josephfischerAug 18, 2025
What to do if the Techman Robot TM Palletizing Operator working pallet disappear cause pause?
- V
  vherreraAug 18, 2025
  If your Techman Robot pauses because the working pallet disappears, it's likely that the pallet sensor isn't detecting the pallet correctly. Ensure the sensor detects the working pallet as it should. Once the sensor is detecting the pallet normally, press the Start button to continue the operation.
A
Alex ReedAug 21, 2025
What to do if Techman Robot Robotics shows 'Air source pressure too low! cause PAUSE'?
- S
  scottkaylaAug 21, 2025
  If your Techman Robot displays 'Air source pressure too low! cause PAUSE', it indicates an abnormal air pressure situation. Check the incoming air pressure value to ensure it is within the specified range. After verifying the air pressure, press the Start button to continue the operation.
K
Kaitlyn SullivanAug 25, 2025
What to do if Techman Robot TM Palletizing Operator shows 'Grab fail cause pause! Resume after checking'?
- C
  Craig WallaceAug 25, 2025
  If your Techman Robot displays 'Grab fail cause pause! Resume after checking,' it means the robot was unable to grab the box on the conveyor. Check the sensor signal on the conveyor to ensure it's functioning correctly. Once you've verified the sensor, press Start to continue the operation.
S
Sandra MurphyAug 27, 2025
What to do if Techman Robot Robotics shows 'Layer Protection! Please remove Right/Left side pallet box cause PAUSE'?
- A
  Andrew KingAug 27, 2025
  If your Techman Robot displays 'Layer Protection! Please remove Right/Left side pallet box cause PAUSE', it means the project paused to prevent the robot from crashing into the opposite working pallet boxes. To resolve this, clear the full state of the pallet and then press the Start button to continue.
K
Kathleen RobertsAug 30, 2025
What to do if Techman Robot TM Palletizing Operator shows 'No box detected on gripper, cause PAUSE'?
- T
  Tonya JamesAug 30, 2025
  If your Techman Robot displays 'No box detected on gripper, cause PAUSE', it indicates that the robot detects abnormal air pressure on the tool when grabbing the box. Check the state of the box dropping and stop the project. Then, restart the project when it is ready.
C
cookdennisSep 3, 2025
What to do if Techman Robot TM Palletizing Operator Robotics shows 'Project initial with box on tool, cause pause'?
- S
  Stephanie ChaseSep 3, 2025
  If your Techman Robot project starts with a box already on the tool and pauses, follow these steps: * Press the Stop button to halt the project. * Remove the box from the gripper. * Place the box in the designated picking position. * Press the Start button to restart the project.
M
Mrs. Kelsey EvansSep 6, 2025
Why Techman Robot Robotics shows Safety Input Discrepancy Status?
- D
  Deborah JonesSep 7, 2025
  The 'Safety Input Discrepancy Status' on your Techman Robot indicates conflicting signals in the safety mechanism. To resolve this: * First, fix the safety input wirings. * Next, make the dual inputs open and close again. At this time, the robot will power on again. * Then, press the reset button when the button light is on. * Finally, press the Stop button on the robot stick or the reach pendant for about three seconds. The robot will calibrate in the start-up process and return to the previous operating mode.
A
Allison PetersenSep 9, 2025
How to adjust the pillar height of Techman Robot TM Palletizing Operator?
- R
  Regina ThompsonSep 10, 2025
  To adjust the pillar height on your Techman Robot, follow these steps: * Press the reset button when the button light is on. * In TMflow, navigate to ? > Setting > Controller. * Click on the IO tab. * Set DO_6 to H (high) and pause briefly, then set DO_6 to L (low) to reset the pillar. * Set DO_0 to L to lower the pillar or H to raise it. * Set DO_1 to H to drop the pillar to its lowest position.
