TM Palletizing Operator User’s Manual Product Version: 1.0 / Document Version: 1.0 28

Figure 9: Pneumatic Diagram

1.5 How Can I Get Help

You can access information sources on Techman Robot website:

http://tm-robot.com/

1.5.1 Related Documentations to this Manual

The documentations listed in the table below have more or less relation to this user manual. For details,

consult with Techman Robot personnel if you’d like to obtain the related documents.

Documents

Descriptions

TMflow Software Manual

Related to Chapter 6 of this manual

TMvision Software Manual

Related to Chapter 6 of this manual

TM12 & TM 14 Hardware Installation

Manual (Medium & Heavy Payload Series)

Related to the safety and hardware installation of this

manual

Safety Manual (Techman Robot Safety

System 3.2)

Related to Chapter 2 and Chapter 3 of this manual

Table 4: Related documentations
