Techman Robot TM Palletizing Operator - Figure 14: Palletizing Operator Clearance with Straight Conveyor; Figure 15: Safeguarded Space Setup Scenario with Sideways Conveyor Layouts

To Next Page

To Previous Page

TM Palletizing Operator User’s Manual Product Version: 1.0 / Document Version: 1.0 48

pallet as shown below.

The box location in this figure indicates the position where the robot will grip the box.

Figure 14: Palletizing operator clearance with straight conveyor

2. Safeguard device (SF3, SF4) and software limits (SF15-Cartesian limit) have to be set before the machine is

taken into operation. Instruction for sideways conveyor layouts had shown as below:

Figure 15: Safeguarded space setup scenario with sideways conveyor layouts

Operating Space

Restricted Space

Safeguarded space

Safeguard Pause

Safeguard Human-Machine

Safety Settings

Conveyor

500mm

Box location where robot

grips box
