Techman Robot TM Palletizing Operator - Figure 68: TM Palletizing Operator Transportation (2;4); Figure 69: TM Palletizing Operator Transportation (3;4)

To Next Page

To Previous Page

TM Palletizing Operator User’s Manual Product Version: 1.0 / Document Version: 1.0 95

Figure 68: TM Palletizing Operator Transportation (2/4)

For jack lifts narrower than 550mm (typically 540mm wide), insert the jack lift into the rear slot to lift the operator.

Figure 69: TM Palletizing Operator Transportation (3/4)

When transporting TM Palletizing Operator with robot arm remaining on top of the

Palletizing Operator Base, it is necessary to tie and surround the robot arm with durable

packing materials to protect it from potential damage.
