Techman Robot TM Palletizing Operator - Table 6: Denotations of Labels

To Next Page

To Previous Page

TM Palletizing Operator User’s Manual Product Version: 1.0 / Document Version: 1.0 37

Label

Denotations

Crushing of hands

Avoid injury to hands when in the vicinity of

equipment with closing mechanical parts

Electricity hazard

Avoid coming into contact with electricity

Do not walk or stand here

Prohibit walking or standing on a designated

area

Connect an earth terminal to the ground

An earth terminal must be connected

Product label

Table 6: Denotations of labels
