Techman Robot TM Palletizing Operator - Table 32: Relevant Parameters

To Next Page

To Previous Page

TM Palletizing Operator User’s Manual Product Version: 1.0 / Document Version: 1.0 158

Relevant Parameters

Parameter

Description

TMOperator_TMROBOT_TMPLTZOP_V001_Main1_var_now_

layer_inder

Current number of layers (including intervals)

TMOperator_TMROBOT_TMPLTZOP_V001_Main1_var_box_i

nfo[2]

Box height (mm)

var_Box_Height-TMOperator_TMROBOT_TMPLTZOP_V001_

Main1_var_pillar_now

Current pillar height (mm)

TMOperator_TMROBOT_TMPLTZOP_V001_Main1_var_now_

right_left

Current palletizing direction

1: right

2: left

TMOperator_TMROBOT_TMPLTZOP_V001_Main1_var_via_p

oint_way

Via Point direction

1: go

2: return

Table 32: Relevant parameters
