Techman Robot TM Palletizing Operator - Figure 134: Move the Robot to Grip the Box; Figure 135: Go to Step 3

To Next Page

To Previous Page

TM Palletizing Operator User’s Manual Product Version: 1.0 / Document Version: 1.0 141

Figure 134: Move the robot to grip the box

IMPORTANT:

Do NOT move or touch the box during this step. Otherwise, the teaching may fail.

4. Go to “Step3_Teach Gripping Point” to set gripping points.

Figure 135: Go to “Step 3”

5. Click on “Point Manager” to set overwrite, as the robot has already been guided about the

gripping point.
