I Hardware Installation Manual 5. Electrical Interface
58
TM5/ TM5X Series: The table below shows the electrical specifications:
TM5M Series electrical specifications as below:
Parameters Minimum value
Typical value
Maximum value
Unit
Input voltage 100 - 240 VAC
External mains fuse
(100V~120V)
- - 15 A
External mains fuse
(200V~240V)
- - 8 A
Input frequency 43 - 63 Hz
Parameters
24V
Minimum
value
Typical
value
Maximum
value
Unit
Input
voltage
20 - 32 V (DC)
Power
consumption
- 1000 W
Parameters
48V
Minimum
value
Typical
value
Maximum
value
Unit
Input
voltage
36 - 60 V (DC)
Power
consumption
- - 1300 W
1. Ensure that the robot is correctly grounded (electrical grounding).
2. Ensure that the input current of the control box is protected by the Residual Current
Device (RCD) and appropriate fuses.
3. Ensure that all cables are correctly connected before the control box is energized.
Always use genuine power cables correctly.
Danger
