tftpFilename - This field sets the filename of the new SW image.
Reset - This field executes a SW reset of the QAM6. It is almost user transparent but will create a
brief video glitch on the channels it is modulating.
Application Notes:
The QAM6 supports an emergency broadcast override. If a video stream is sent to port 25600
it will override all of the channels.
Some QAM6 boards have an RF spur that can interfere with analog television channels. The
spur is 1176 MHz minus the desired center RF frequency for each group of four channels. For
channels 23 through 94 this means that the spur will be at (1086 – 6 * channel) MHz Change
the frequency plan to minimize the impact of the RF spurs.
