Technifor XF510Cr User Manual

AInstallation
C
Ref. DCD01/3074 - XF510Cr-Sr-Dr_en_C
18/31
Efforts given for an operating pressure of 6 Bar (87.023 PSI) (when pressure varies, apply the rule of
proportionality)
Approximative forces exerted on the part to mark
Stylus
NA0 NA1 NA1 LG 100 N2 NA2
Fx = Fy (daN) ± 8.0 ± 18.8 ± 18.8 ± 36.9 ± 36.9
Fz (daN) 8.0 18.8 18.8 36.9 36.9
Cy max (daN.m) 1.8 4.2 5.1 7.6 8.3
Cy min (daN.m) -1.0 -2.3 -3.1 -3.9 -4.5
Cx max (daN.m) 2.1 4.9 5.8 9.1 9.7
Cx min (daN.m) -0.7 -1.6 -2.4 -2.4 -3.0
Cz (daN.m) ± 1.1 ± 2.7 ± 2.7 ± 5.2 ± 5.2
Stylus
NA0 NA1 NA1 LG 100 N2 NA2
Fx = Fy (daN) ± 8.0 ± 18.8 ± 18.8 ± 36.9 ± 36.9
Fz (daN) -8.0 -18.8 -18.8 -36.9 -36.9
