TechniSat DIGITRADIO 2 User Manual

101
DE
EN
FR
IT
NL
PL
CZ
5.3.2 Connecting the power supply unit
> To do this, connect the mini USB plug on the power supply unit included with
the DC IN jack labelled on the side of the DIGITRADIO. Then connect the power
supply unit to the mains supply.
Ensure that the operating voltage of the power supply unit matches the mains
voltage before you insert it into the wall socket.
Aer establishing the mains connection for the first time "TechniSat Digital
Radio" appears on the display. You can then select the operating language. To do
this, select one of the available languages using the <or > keys and confirm the
selection by pressing the OK key. A channel search is then performed via DAB+
for the first time. Please refer to the information in Section 5.4.1.

TechniSat DIGITRADIO 2 Specifications

General

Radio type	Portable
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, VHF
Power source	AC/Battery
AC input voltage	230 V
AC input frequency	50 Hz
Package width	190 mm
Package height	55 mm
Package weight	654 g
Headphone outputs	1
USB charging port	Yes
Headphone connectivity	3.5 mm
RMS rated power	1 W
Thermometer	-
Product color	Black, Silver
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
Display type	OLED
Battery voltage	3.7 V
Battery capacity	1050 mAh
Battery life (max)	10 h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Cables included	USB

Weight and Dimensions

Depth	47 mm
Width	175 mm
Height	109 mm
Weight	344 g
