TechniSat DIGITRADIO 2 User Manual

134
Only clean the display with a so, coon cloth. If required, use a coon cloth with
small amounts of non-alkaline, diluted, water or alcohol-based soap solution.
Gently clean the surface using the coon cloth.
14 Troubleshooting
If the device does not operate as intended, check the following table for information.
Symptom Possible cause/remedy
The device cannot be switched on. The device is not being supplied with power.
Connect the power supply unit correctly to the
socket and to the device. Charge the baery.
No sound can be heard. Increase the volume.
The display does not switch on. Disconnect the device from the mains supply,
remove the baery and reconnect the device to
the mains.
Poor reception via DAB+/FM. Extend the antenna. Change the position of the
antenna or the DIGITRADIO.

TechniSat DIGITRADIO 2 Specifications

General

Radio type	Portable
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, VHF
Power source	AC/Battery
AC input voltage	230 V
AC input frequency	50 Hz
Package width	190 mm
Package height	55 mm
Package weight	654 g
Headphone outputs	1
USB charging port	Yes
Headphone connectivity	3.5 mm
RMS rated power	1 W
Thermometer	-
Product color	Black, Silver
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
Display type	OLED
Battery voltage	3.7 V
Battery capacity	1050 mAh
Battery life (max)	10 h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Cables included	USB

Weight and Dimensions

Depth	47 mm
Width	175 mm
Height	109 mm
Weight	344 g
