TechniSat DIGITRADIO 2 User Manual

135
DE
EN
FR
IT
NL
PL
CZ
Symptom Possible cause/remedy
The device cannot be operated. Disconnect the device from the mains supply,
remove the baery and reconnect the device to
the mains.
Bad Bluetooth connection and
dropouts
Do not exceed the maximum range for Bluetooth
of 10m.
If the malfunction has not been resolved, even aer performing the checks described,
please contact the Technical Hotline.
15 Technical specifications / manufacturer's instructions
Subject to technical changes and errors.
Reception channels DAB/DAB+, FM, Bluetooth
power supply AC Input: 100-240V, 50 / 60Hz
DC Output: 5V, 2A (DIGITRADIO 2S)
DC output: 5V, 1A (DIGITRADIO 2)
Baery 3.7V / 1050 mAh Li-Ion, charging current
max. 500 mA
Baery life up to 10 hours (speaker at
medium volume)

TechniSat DIGITRADIO 2 Specifications

General

Radio type	Portable
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, VHF
Power source	AC/Battery
AC input voltage	230 V
AC input frequency	50 Hz
Package width	190 mm
Package height	55 mm
Package weight	654 g
Headphone outputs	1
USB charging port	Yes
Headphone connectivity	3.5 mm
RMS rated power	1 W
Thermometer	-
Product color	Black, Silver
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
Display type	OLED
Battery voltage	3.7 V
Battery capacity	1050 mAh
Battery life (max)	10 h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Cables included	USB

Weight and Dimensions

Depth	47 mm
Width	175 mm
Height	109 mm
Weight	344 g
