TechniSat DIGITRADIO 2 User Manual

108
The display can also be changed by briefly holding down the one-touch buon.
6 Menu operation
The menu takes you to all functions and seings of the DIGITRADIO. Menu navigation is
carried out with the MENU, <,> and OK buons. The menu is divided into submenus and
contains dierent menu items or activatable functions depending on the mode (DAB+
or FM). To open the menu, simply press the MENU buon briefly. To switch to submenus,
first press the < or > buons to display a submenu, then press the OK buon to access
the submenu. An asterisk (*) highlights the current selection.
To close the menu: Press the MENU buon several times (depending on which
submenu you are in) until the current radio channel is displayed again.
Seings are not saved until the OK buon is pressed. If the MENU buon is
pressed instead of this, the seings are not accepted or saved (the MENU buon
in this case acts as a “Back” buon).

TechniSat DIGITRADIO 2 Specifications

General

Radio type	Portable
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, VHF
Power source	AC/Battery
AC input voltage	230 V
AC input frequency	50 Hz
Package width	190 mm
Package height	55 mm
Package weight	654 g
Headphone outputs	1
USB charging port	Yes
Headphone connectivity	3.5 mm
RMS rated power	1 W
Thermometer	-
Product color	Black, Silver
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
Display type	OLED
Battery voltage	3.7 V
Battery capacity	1050 mAh
Battery life (max)	10 h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Cables included	USB

Weight and Dimensions

Depth	47 mm
Width	175 mm
Height	109 mm
Weight	344 g
