TechniSat DIGITRADIO 2 User Manual

114
> Use the < or > buons to select the [Signal strength] item and press OK.
> Exit the menu by pressing the MENU buon several times.
> The display shows the signal strength using a bar graph.
Stations with a signal strength below the required minimum signal intensity
are not transmiing a strong enough signal. Align the telescopic antenna as
described in section 5.3.3 if required.
7.2.7 Manual seing
This menu item is used to check the reception channels and can be used to position the
antenna.
> Briefly press the MENU buon, use the < or > buons to select the [Set
manually] item and press the OK buon.
> Use the < or > and OK buons to select a channel (5A to 13F). The signal
strength will now be shown on the display. If a DAB+ station is being received
on a channel, the station ensemble name is displayed. The antenna can now be
aligned to the maximum signal intensity.

TechniSat DIGITRADIO 2 Specifications

General

Radio type	Portable
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, VHF
Power source	AC/Battery
AC input voltage	230 V
AC input frequency	50 Hz
Package width	190 mm
Package height	55 mm
Package weight	654 g
Headphone outputs	1
USB charging port	Yes
Headphone connectivity	3.5 mm
RMS rated power	1 W
Thermometer	-
Product color	Black, Silver
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
Display type	OLED
Battery voltage	3.7 V
Battery capacity	1050 mAh
Battery life (max)	10 h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Cables included	USB

Weight and Dimensions

Depth	47 mm
Width	175 mm
Height	109 mm
Weight	344 g
