TechniSat DIGITRADIO 2 User Manual

104
5.4 General device functions
5.4.1 Switching on the device
> In order to guarantee good DAB+/FM reception, please fully extend the antenna
located on the rear of the device. To do so, please refer to Section 5.3.3.
> First prepare the DIGITRADIO for operation as described in sections 5.3.1 and
5.3.2.
> Press the On / Standby buon on the top of the unit to turn on the DIGITRADIO 2.
Aer switching on the device for the first time, you must first set the [Language].
To do this, select one of the available languages using the < or > keys and
confirm the selection by pressing the OK key. The device then automatically
performs a full channel search in DAB+ mode. While scanning, the display
information shows the progress as well as the number of digital radio stations
detected. Aer completing the station scan the first DAB+ channel is played.

TechniSat DIGITRADIO 2 Specifications

General

Radio type	Portable
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, VHF
Power source	AC/Battery
AC input voltage	230 V
AC input frequency	50 Hz
Package width	190 mm
Package height	55 mm
Package weight	654 g
Headphone outputs	1
USB charging port	Yes
Headphone connectivity	3.5 mm
RMS rated power	1 W
Thermometer	-
Product color	Black, Silver
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
Display type	OLED
Battery voltage	3.7 V
Battery capacity	1050 mAh
Battery life (max)	10 h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Cables included	USB

Weight and Dimensions

Depth	47 mm
Width	175 mm
Height	109 mm
Weight	344 g
