TechniSat DIGITRADIO 2 User Manual

106
5.4.3 Changing to DAB+/FM/Bluetooth mode
> Press the MODE buon to switch between DAB+ (Digital Radio), FM and
Bluetooth.
5.4.4 Adjusting the volume
> Adjust the volume with the Volume +/- buon. The set volume is shown on
the display by way of a bar chart. Also refer to Section 5.3.4 for operation when
headphones are connected.
5.4.5 Display
Depending on the selected function or option, the display will show the following
information:
Sendername,
Frequenz,
Menüname
Displayanzeigen,
Menüoptionen,
Lautstärke
Ladezustand
des Akku
Station name,
frequency,
menu name
Status of charge
of the baeries
Visual display,
menu options,
volume

TechniSat DIGITRADIO 2 Specifications

General

Radio type	Portable
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, VHF
Power source	AC/Battery
AC input voltage	230 V
AC input frequency	50 Hz
Package width	190 mm
Package height	55 mm
Package weight	654 g
Headphone outputs	1
USB charging port	Yes
Headphone connectivity	3.5 mm
RMS rated power	1 W
Thermometer	-
Product color	Black, Silver
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
Display type	OLED
Battery voltage	3.7 V
Battery capacity	1050 mAh
Battery life (max)	10 h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Cables included	USB

Weight and Dimensions

Depth	47 mm
Width	175 mm
Height	109 mm
Weight	344 g
