TechniSat DIGITRADIO 2 User Manual

111
DE
EN
FR
IT
NL
PL
CZ
7.2 DAB+ (digital radio) reception
> Press the MODE buon until [DAB] is shown on the display.
If DAB+ is being started for the first time, a complete scan will be performed.
Aer the scan is complete, the first station is played back in alphanumeric order.
7.2.1 Performing a complete scan
The automatic scan (Complete scan) scans all DAB+ band III channels and
thereby finds all stations being broadcast within the reception area.
Aer the scan is complete, the first station is played back in alphanumeric order.
> In order to perform a complete scan, open the menu by pressing the MENU
buon and use the <, > and OK buons to select the menu item [Complete
Scan].
> [Scanning...] appears on the display.
During the scan a progress bar and the number of stations found is displayed.

TechniSat DIGITRADIO 2 Specifications

General

Radio type	Portable
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB band range	174 - 240 MHz
Supported radio bands	DAB, DAB+, VHF
Power source	AC/Battery
AC input voltage	230 V
AC input frequency	50 Hz
Package width	190 mm
Package height	55 mm
Package weight	654 g
Headphone outputs	1
USB charging port	Yes
Headphone connectivity	3.5 mm
RMS rated power	1 W
Thermometer	-
Product color	Black, Silver
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
Display type	OLED
Battery voltage	3.7 V
Battery capacity	1050 mAh
Battery life (max)	10 h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Cables included	USB

Weight and Dimensions

Depth	47 mm
Width	175 mm
Height	109 mm
Weight	344 g
